PanelFrame MKII Fixed Frame Screen

PanelFrame MKII Fixed Frame Screen


Features:-
  • Modern panel TV style with ultra-narrow barrel
  • Rigid Aluminum frame structure with internal insert corner brackets
  • Powder coated in black
  • Spring mounted fabric offer the best tensional uniformity and overall flatness
  • Reliable wall mount bracket simplifies the difficulties during installation

User Manaul

Specifications

Product Code

Screen Size

Viewing Area(mm)

Frame Size (mm)

Packing Dimension LxWxH(mm)

N.W. (kg)

G.W. (kg)

(HxW, inches)

Height

Width

16:9 HDTV Format

PF2045080

92"(45"x80")

1145

2036

12

2350*270*120

12.1

13.6

PF2049087

100"(49"x87")

1245

2213

12

2490*270*120

13.5

15.0

PF2054096

110"(54"*96")

1375

2442

12

2610*270*120

13.9

15.4

PF2059104

120”(59”x104”)

1494

2656

12

2840*270*120

15.7

17.2

PF2064113

130”(64”x113”)

1619

2877

12

3050*270*120

18.0

19.5

PF2069122

140”(69”x122”)

1743

3099

12

3270*270*120

20.0

21.5
